Supreme Cable Technology, Inc.100% tests all assemblies when possible. We test them using the latest equipment offered by Cirris Systems, Inc. Often, test fixtures are made to interface between your assembly and the Cirris tester.
- Test Point Range: 128-1024
- Test Voltage: 5VDC, 6mA max current
- Connection Resistance Range: 0.1-100KΩ, also 500KΩ, 1MΩ, 5MΩ
- 4-Wire Resistance Range: .005Ω to 10Ω
- Testable Components: Resistors, Diodes, Capacitors
- Scripting Support: Optional
- Onboard Memory Capacity: 99 wirelists
- Test Rates: 128 pts / .25 sec. (typical)
- Usable Adapter Sizes: single, double and quad high.
- Power: 100-250VAC, 50-60 Hz, Max 50W.
